Manufacturing Facilities

WorkShop Details

  • Shop Floor - Work shop place with machines Equipments.
    1) Area of Plot 6300 SQ. MTR. (Built-up shed with H.O.T. Gantry)
    2) Workshop 1000 SQ. MTR.
    3) Machine shop 1000 SQ. MTR.
  • Office Building - Total Area 200 SQ. MTR. With Fully Furnish With All Minimum office Equipments
  • Store Room - Area 50 SQ. MTR. With Racks and Storage Systems for Consumables

Manufacturing Facilities

Work Shop Place with Machines Equipments.
  • Area of Plot 2100 SQ. MTR. (Built-up shed with H.O.T. Gantry)
  • Workshop 300 SQ. MTR.
  • Machine shop 200 SQ. MTR.

List of Machines

Sr. No. Type of M/C & Code Electric Parameter Other Specifications.
1)

1 Lath Machine
 Make B. Parmar.
 (LM01)

1) Motor 7.5 HP.
2) Motor Auto 1HP.

2)

Lath Machine
Make PSG Motor Ltd. (LM02)

 1) Motor 12.5 HP.
3)

Lath Machine
Make PSG Motor Ltd. (LM03)

 1) Motor 7.5 HP.
4)

VTL Machine
 Model 3 M VTL
 (VTL01
)

1) Main Motor Table Drive – 30 HP
2) Automatic Lifting & Lower of cross Rail Motor – 3 HP
3) Vert /Horz Feed of Ram Slide Motor – 3 HP
4) VFD Drive
5) DRO- Electronica




5)

VTL Machine
Model 2 M VTL
(VTL02)

1) Main Motor Table Drive – 30 HP
2) Automatic Lifting & Lower of cross Rail Motor – 3 HP
3) Vert /Horz Feed of Ram Slide Motor – 3 HP
4) VFD Drive
5) DRO- Electronica




6)

Hydraulic Press M/C

1) Motor 10 HP. Make Electro.

1) Capacity 100 Mt.
2) Maximum Dia Dish end 3 Mtr.

7)

Chain Pulley Block
Make V-Tal




1) Trolley Capacity 2 Ton.
2)  Chain Pulley Block Capacity 3 Ton.
3) Lifting 3 Mtr.
4) Span 7 Mtr.

8)

Pug Cutting M/C
Make ESAB


9)

Hydro Testing Machine
(Electric)

1) Motor 2.2 HP. Make Jyoti Elect.

1) Capacity 60Kg/cm2

10)

Hydro Testing Machine
(Hand Operating)

1) Motor 3 HP. Make Hindustan

1) Capacity 50Kg/cm2

11)

Drilling Machine

As Per Manual.

1) M/C Height 2.560 Mtr.
2) Length 2450.
3) Bed Length 1 Mtr.

12)

HOT Crane No-1

Hoist Electric 2 Ton SWL No 4215 Make Crane ‘O’ Mech. Engg.

Capacity 2 Ton,
Cross Travel 7.72 Mtr.
Lift 3.550 Mtr.

13)

HOT Crane No-2/1

Hoist Electric 2 Ton Crane ‘O’ Mech. Engg.

Capacity 3 Ton,
Cross Travel 8.60 Mtr.
Lift 3.400 Mtr.
Long Travel 24.150

14)

HOT Crane No-2/2

Hoist Electric 2 Ton Crane ‘O’ Mech. Engg.

Capacity 3 Ton,
Cross Travel 8.60 Mtr.
Lift 3.400 Mtr.
Long Travel 24.150



15)

HOT Crane No-2/2

Hoist Electric 5 Ton Self Made Anant Hydro Engineers L L P.

Capacity 5 Ton,
Cross Travel 11.300 Mtr.
Lift 3.800 Mtr.
Long Travel 23.300

16)

OVEN

Temp – 350 - 370°C
Range – 70 V
Capacity 2 Kgs.

1) M/C Height 330.
2) Length 260.
3) Width 260.

17)

Redial Drill M/C Small

2 HP Motor make National Engineering

1) M/C Height 330.
2) Length 260.
3) Width 260.
M/C Capacity 32 mm.

18)

Bench Grinder

Motor 0.5 HP.

Size 8”

19)

Welding M/C No-1
Swastik Make

ARC welding Inverter MMA4003
Current Capacity 400 AMP

1) M/C Height 490.
2) Length 610.
3) Width 320.

20)

Welding M/C No-2
Warpp Make

ARC welding Inverter MMA4003
Current Capacity 400 AMP

1) M/C Height 570.
2) Length 650.
3) Width 310.

21)

Welding M/C No-3
Warpp Make

ARC welding Inverter MMA4003
Current Capacity 400 AMP

1) M/C Height 570.
2) Length 650.
3) Width 310.




1-Lathe-Machine

Lathe Machine
Make B. Parmar.(LM01)

Electric Parameter

  • Motor 7.5 HP.
  • Motor Auto 1HP.

Mechanical Parameter

  • Center Height 1.75 Mtr.
  • M/C Height 2.560 Mtr.
  • Length 4.400 Mtr.
  • Width 3.310 Mtr.
  • Length of M/c Job 1.5 Mtr.
lathe-machine-with-long-bed

Lathe Machine
With Long Bed (LM02)

Electric Parameter

  • Motor 12.5 HP.

Mechanical Parameter

  • Center Height 1.75 Mtr.
  • M/C Height 2.560 Mtr.
  • Length 4.400 Mtr.
  • Width 3.310 Mtr.
  • Length of M/c Job 1.5 Mtr.
vtl-machine-model

Hydraulic Press M/C

Electric Parameter

  • Motor 10 HP.
  • Make Electro.

Mechanical Parameter

  • Capacity 100 Mt.
  • Maximum Dia Dish end 3 Mtr.
hyadraulic-press

VTL Machine
Model 3 M VTL (VTL01)

Electric Parameter

  • Main Motor Table Drive – 30 HP
  • Automatic Lifting & Lower of cross Rail Motor – 3 HP
  • Vert /Horz Feed of Ram Slide Motor – 3 HP
  • VFD Drive
  • DRO- Electronica

Mechanical Parameter

  • Table Diameter – 3000mm.
  • Turning Diameter – 3500mm
  • Working Height cross Rail-2000mm
  • Vertical travel of Ram Head-1200mm
  • Swivel Angle of Ram Head - 45º
  • Table Speed – 1.5 to 15 Rpm
drilling-machine

Drilling Machine

Electric Parameter

  • Drilling Machine
  • Spindle Moter 1.5 hp

Mechanical Parameter

  • M/C Height 2.560 Mtr.
  • Length 2450.
  • Bed Length 1 Mtr.
  • Driling Diameter 65mm
bending-machine

Bending Machine

Electric Parameter

  • Make

Mechanical Parameter

  • Length - 2000mm
  • Minimum Dia. 700mm
  • Thickness - 35mm
  • Hydraulic Oprated
  • DRO For Roller Position
  • PLC Control
saw-welding-machine

Saw Welding Machine And Positioner

Electric Parameter

  • Arc Power Control Pune Thyristor Based 40hp Capacity Turn Table Motor 5 hp

Mechanical Parameter

  • Current Capacity 800 Amp Wire Size 2mm
  • 3.1mm Turn Table max Dia. Of Job 2500mm
Lathe Machine With Medium Bed (LM03)

Lathe Machine With Medium Bed (LM03)

Electric Parameter

  • Lathe Machine With Medium Bed (LM03)

Mechanical Parameter

  • Center Height 1.68 Mtr.
  • M/C Height 1.68 Mtr.
  • Length 6.230 Mtr.
  • Width 3.310 Mtr.
  • Length of M/c Job 1.0 Mtr.
Radial Drill M/C Small

Radial Drill M/C Small

Electric Parameter

  • 2 HP Motor make National Engineering

Mechanical Parameter

  • M/C Height 330.
  • Length 260.
  • Width 260.
  • M/C Capacity 32 mm.
Pug Cutting M/C Make ESAB

Pug Cutting M/C Make ESAB

Electric Parameter

Mechanical Parameter

  • Cutting Capacity 200mm (MS)
  • Circle Min. Dia. 400mm
Hydro Testing Machine (Electric)

Hydro Testing Machine (Electric)

Electric Parameter

  • Motor 2.2 HP. Make Jyoti Elect.

Mechanical Parameter

  • Capacity 60Kg/cm2
HOT Crane No-1

HOT Crane No-1

Electric Parameter

  • Hoist Electric 2 Ton SWL No 4215 Make Crane ‘O’ Mech. Engg.

Mechanical Parameter

  • Capacity 2 Ton
  • Cross Travel 7.72 Mtr.
  • Lift 3.550 Mtr.
HOT Crane No-2/1

HOT Crane No-2/1

Electric Parameter

Mechanical Parameter

  • Capacity 3 Ton
  • Cross Travel 8.60 Mtr.
  • Lift 3.400 Mtr.
  • Long Travel 24.150
HOT Crane No - 2/2

HOT Crane No - 2/2

Electric Parameter

  • Hoist Electric 2 Ton Crane ‘O’ Mech. Engg.

Mechanical Parameter

  • Capacity 3 Ton
  • Cross Travel 8.60 Mtr.
  • Lift 3.400 Mtr.
  • Long Travel 24.150
HOT Crane No - 2/2

HOT Crane No - 2/2

Electric Parameter

  • Hoist Electric 2 Ton Crane ‘O’ Mech. Engg.

Mechanical Parameter

  • Capacity 3 Ton
  • Cross Travel 8.60 Mtr.
  • Lift 3.400 Mtr.
  • Long Travel 24.150
OVEN

OVEN

Electric Parameter

  • Temp – 350 - 370°C
  • Range – 70 V
  • Capacity 2 Kgs.

Mechanical Parameter

  • M/C Height 330.
  • Length 260.
  • Width 260.
Welding M/C No - 1
Swastik Make

Welding M/C No - 1 Swastik Make

Electric Parameter

  • HP Capacity 9.5
  • Current Capacity 400 AMP

Mechanical Parameter

  • M/C Height 490.
  • Length 610.
  • Width 320.
  • Current Capacity 400 AMP
  • ARC welding Inverter MMA4003
Welding M/C No - 2 Warpp Make

Welding M/C No - 2 Warpp Make

Electric Parameter

  • HP Capacity 9.5
  • Current Capacity 400 AMP

Mechanical Parameter

  • M/C Height 570.
  • Length 650.
  • Width 310.
  • Current Capacity 400 AMP
Welding M/C No.-3 Warpp Make

Welding M/C No.-3 Warpp Make

Electric Parameter

  • HP Capacity 9.5
  • Current Capacity 400 AMP

Mechanical Parameter

  • ARC welding Inverter MMA4003
  • M/C Height 570.
  • Length 650.
  • Width 310.
  • Current Capacity 400 AMP

Grinder 7” No 1 & 2
Grinder 7” No 3 & 4
Grinder 7” No 5
Grinder 5” No 1 & 2
Sander 7”

Electric Parameter

  • KPT make
  • Ideal make
  • Boss make Fiber Body
  • Ideal make
  • KPT Make

Mechanical Parameter
